Raythink handheld thermal cameras

EX10 specifications

<strong>Thermal Imaging</strong> Infrared Resolution;160×120 Super Resolution;320×240 Spectral Band;8–14 μm NETD;40 mK Frame Rate;25 Hz Lens Focal Length;2.6 mm FOV;40°×30° IFOV;4.62 mrad Focusing Mode ;Fixed focus Minimum Imaging Distance;11 cm Measurement Range;20 ~ 150℃, 100 ~ 550℃, auto switching <strong>Imaging Display</strong> Display;2.8-inch 240×320 Palettes;6 options Image Mode;Infrared Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;8GB Internal memory Image File Format;JPEG <strong>Recording and Transmission</strong> Communication Interface;USB2.0 Video Transmission;UVC (with temperature data) <strong>Measurement and Analysis</strong> Measurement Accuracy;±2°C or ±2% of readings (whichever is greater) Measurement Unit;Celsius degree, Fahrenheit degree, Kelvin Temperature Alarm;Supports (high and low temperature alarms) Automatic lmage Capture Upon Alarm;Supports (with temperature data) Color Alarm (lsotherm);Above / Below / Between — The image within the isotherm range is displayed in pseudo color, while other areas are shown in white-hot mode Analysis Functions on the Device;Central point / Highest temperature point / Lowest temperature point / 3 custom points Analysis Report;PDF format(requiring support from PC analysis software) Supporting Software;PC (Infrared Analysis Software) <strong>System Functions</strong> Connection Mode;USB2.0 Type-C Laser Pointer;Not support Quick Start;Support WiFi;Not support <strong>Others</strong> Battery;2750 mAh lithium-ion battery Charging Time;Above 90% within 75 minutes Charging Mode;USB2.0, Type-C cable charging, Not support fast charging Battery Life;≥10 hours Tripod Socket;Support Operating Temperature;-20°C ~ 50°C Storage Temperature;-40°C ~ 70°C Extrnal Interface;Type-C USB2.0 Tripod socket Ingress Protection Rating;IP54 Shock and Vibration;shock: 25G (IEC60068-2-27), vibration: 2.5G (IEC60068-2-6), 2-meter drop Weight and Dimensions;257±10 g (including battery), 206.9×67×81.5 mm Packing List;Infrared thermal camera, user manual, USB cable, certificate of qualfication, calibration certificate, wrist strap

EX10 Pro specifications

<strong>Thermal Imaging</strong> Infrared Resolution;160×120 Super Resolution;320×240 Spectral Band;8–14 μm NETD;40 mK Frame Rate;25 Hz Lens Focal Length;2.6 mm FOV;40°×30° IFOV;4.62 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;11 cm Measurement Range;-20~150℃, 100~550℃, auto switching <strong>Imaging Display</strong> Display;2.8-inch 240×320 Visible Light Camera;2 megapixels Palettes;9 options Image Mode;Infrared, visible light, PIP, fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;8GB Internal Memory Image File Format;JPEG <strong>Video Recording and Transmission</strong> Communication Interface;USB2.0 Video Recording;Standard MP4 video recording Video Resolution;240×320 Video Transmission;UVC (with temperature data) + Wi-Fi (without temperature data) <strong>Measurement and Analysis</strong> Measurement Accuracy;±2°C or ±2% of readings (whichever is greater) Measurement Unit;Celsius degree, Fahrenheit degree, Kelvin Temperature Alarm;Supports (high and low temperature alarms) Automatic lmage Capture Upon Alarm;Supports (with temperature data) Color Alarm (lsotherm);Above/Below/Between — The image within the isotherm range is displayed in pseudo color, while other areas are shown in white-hot mode Analysis Functions on the Device;Central point/Highest temperature point/Lowest temperature point/6 custom points Analysis Report;PDF format (requiring support from PC or APP analysis software) Supporting Software;PC (Infrared Analysis Software) or Mobile (iOS/ Android APP) <strong>System Functions</strong> Connection Mode;USB2.0 Type-C Laser Pointer;Supports Quick Start;Supports WiFi;Supports <strong>Others</strong> Battery;2750 mAh lithium-ion battery Charging Time;Above 90% within 75 minutes Charging Mode;USB2.0, Type-C cable charging, does not support fast charging Battery Life;≥10 hours Tripod Socket;Supports Operating Temperature;-20°C~ 50°C Storage Temperature;-40°C~ 70°C External Interface;Type-C USB2.0 Tripod socket Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25G (IEC60068-2-27), vibration: 2.5G (IEC60068-2-6), 2-meter drop Weight and Dimensions;265g±10g (including battery), 206.9×67×81.5mm Packing List;Infrared thermal camera, user manual, USB cable, certificate of qualification, calibration certificate, wrist strap

CX20 specifications

<strong>Thermal Imaging</strong> Detector Type;12 μm Infrared Resolution;256×192 Super Resolution;512×384 Spectral Band;7.5–14μm NETD;＜40mK Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.8 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;Low temperature range: -20–150°C, high temperature range: 100~550°C, auto switching Measurement Accuracy;±2% or ±2°C of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch, 480×640 Digital Zoom;2x, 4x Palettes;7 Image Mode;Infrared Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;32 GB Internal Memory <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Central point/Highest temperature point/Lowest temperature point/3 custom points/Temperature difference Laser Rangefinding;Not support Supporting Software;PC (Infrared Analysis Software) or Mobile (iOS/ Android APP) Laser Pointer;Not support <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Alarm Type;Image pop-ups Power Management;Adjustable (Automatic shutdown, 5 min, 10 min, 20 min, 120 min) Video Transmission;UVC (including full-frame temperature data) + Wi-Fi (excluding full-frame temperature data) Temperature Alarm;Support full-frame highest/lowest temperature alarm, automatic image capture at alarm time (with temperature data) <strong>Others</strong> Battery;Built-in rechargeable lithium-ion battery Charging Mode;USB Type-C Battery Life;6h Tripod Socket;Support Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54/2 m Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;500g, 246X101X85mm Authentication;CB/CE/CMA Packing List;USB cable, user manual, certificate of qualification, calibration certificate, portable bag

CX20 Pro specifications

<strong>Thermal Imaging</strong> Detector Type;12 μm Infrared Resolution;256×192 Super Resolution;512×384 Spectral Band;7.5–14 μm NETD;＜40mK Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.8 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;Low temperature range: -20–150°C, high temperature range: 100~550°C, auto switching Measurement Accuracy;±2% or ±2°C of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch, 480×640 Visible Light Camera;2 megapixels Digital Zoom;2x, 4x Palettes;7 Image Mode;Infrared, fusion, PIP, visible light Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium; 32GB Internal Memory <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Central point/Highest temperature point/Lowest temperature point/3 custom points/Temperature difference Laser Rangefinding;Not support Supporting Software;PC (Infrared Analysis Software) or Mobile (iOS/ Android APP) Laser Pointer;Support <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Alarm Type;Image pop-ups, flash prompts Power Management;Adjustable (Automatic shutdown, 5 min, 10 min, 20 min, 120 min) Video Transmission;UVC (including full-frame temperature data) + Wi-Fi (excluding full-frame temperature data) Temperature Alarm;Support full-frame highest/lowest temperature alarm, automatic image capture at alarm time (with temperature data) <strong>Others</strong> Battery;Built-in rechargeable lithium-ion battery Charging Mode;USB Type-C Battery Life;6 h Tripod Socket;Support Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54/2m Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;500g, 246X101X85mm Authentication;CB/CE/CMA Packing List;USB cable, user manual, certificate of qualification, calibration certificate, charger, portable bag

CX20 Ultra specifications

<strong>Thermal Imaging</strong> Detector Type;12 μm Infrared Resolution;256×192 Super Resolution;512×384 Spectral Band;7.5-14 μm NETD;＜40 mK Frame Rate;25 Hz Lens Focal Length;4.3 mm FOV;40°×30° IFOV;2.79 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.7 m Measurement Range;Low temperature range:-20~150°C, high temperature range:100~550°C, auto switching Measurement Accuracy;±2% or ±2°C of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch, 480×640 Visible Light Camera;2 megapixels Digital Zoom;2x, 4x Palettes;7 Image Mode;Infrared, fusion, PIP, visible light Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;32GB Internal Memory <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Central point/Highest temperature point/Lowest temperature point/6 custom points/Temperature difference Laser Rangefinding;Support, max detection range: 4m Supporting Software;PC (Infrared Analysis Software) or Mobile (iOS/ Android APP) Laser Pointer;Support <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Alarm Type;Image pop-ups, flash prompts Power Management;Adjustable (Automatic shutdown, 5 min, 10 min, 20 min, 120 min) Video Transmission;UVC (including full-frame temperature data) + Wi-Fi (excluding full-frame temperature data) Temperature Alarm;Support full-frame highest/lowest temperature alarm, automatic image capture at alarm time (with temperature data) <strong>Others</strong> Battery;Built-in rechargeable lithium-ion battery Charging Mode;USB Type-C Battery Life;6h Tripod Socket;Support Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54/2m Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;500g, 246X101X85mm Authentication;CB/CE/CMA Packing List;USB cable, user manual, certificate of qualification, calibration certificate, charger, portable bag

CX200 SE+ specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;256×192 Al Real-time Super-resolution;320×240 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜40 mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.8 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;-20°C ~ +150°C, 100°C ~ +550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;2.8 inch, 320×240 Digital Zoom;1×, 2×, 4× Palettes;4 options Image Mode;Infrared Temperature Width Stretch;Auto <strong>Image Storage</strong> Storage Medium;Standard 32GB MicroSD, up to 128GB <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Central temperature point/Highest temperature point/Lowest temperature point Supporting Software;PC (Infrared Analysis Software) <strong>System Functions</strong> Alarm Type;Highest/Lowest temperature alarm in full frame, Image pop-ups, flash prompts, Auto image capture at alarm time (with temperature data). Power Management;Auto shut-down setting <strong>Others</strong> Battery;Built-in rechargeable lithium-ion battery Charging Mode;USB Type-C Battery Life;About 15 h Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 520 g, 237×75×92 mm Authentication;CE/RoHS/CMA, etc. Packing List;Infrared camera×1, USB cable, 32GB SD card, user manual, storage bag, certificate of qualification, calibration certificate

CX200+ specifications

<strong>Thermal Imaging</strong> Detector Type;12 μm uncooled infrared detector Infrared Resolution;256×192 Al Real-time Super-resolution;320×240 Spectral Band;7.5–14 μm NETD;＜40 mK (25°C,F1.0) Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.8 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;2.8 inch, 320×240 Visible Light Camera;2 megapixels Digital Zoom;1×, 2×, 4× Palettes;7 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Auto <strong>Image Storage</strong> Storage Medium;Standard 32GB MicroSD, up to 128G <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Central temperature point/Highest temperature point/Lowest temperature point Supporting Software;PC (Infrared Analysis Software) <strong>System Functions</strong> Alarm Type;Highest/Lowest temperature alarm in full frame, Image pop-ups, flash prompts,Auto image capture at alarm time (with temperature data). Power Management;Auto shut-down setting <strong>Others</strong> Battery;Built-in rechargeable lithium-ion battery Charging Mode;USB Type-C Battery Life;About 15 h Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 520 g, 237×75×92 mm Authentication;CE/RoHS/CMA, etc. Packing List;Infrared camera×1, USB cable, 32GB SD card, user manual, storage bag, certificate of qualification, calibration certificate

CX200 Pro+ specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;256×192 Al Real-time Super-resolution;320×240 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜40mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.8 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;2.8 inch, 320×240 Visible Light Camera;2 megapixels Digital Zoom;1×, 2×, 4× Palettes;7 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Auto <strong>Image Storage</strong> Storage Medium;Standard 32GB MicroSD, up to 128GB <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Central temperature point/Highest temperature point/Lowest temperature point/3 custom points Supporting Software; PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>System Functions</strong> Communication Protocol;USB, WiFi Alarm Type;Highest/Lowest temperature alarm in full frame, Image pop-ups, flash prompts, Auto image capture at alarm time (with temperature data). Power Management;Auto shut-down setting <strong>Others</strong> Battery;Built-in rechargeable lithium-ion battery Charging Mode;USB Type-C Battery Life;About 15 h Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 520g, 237×75×92mm Authentication;CE/RoHS/CMA, etc. Packing List;Infrared camera×1, USB cable, 32GB SD card, user manual, storage bag, certificate of qualification, calibration certificate

IX2 AIR specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;256×192 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜40mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.75 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2ºC or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Visible Light Camera;2 MP Palettes;7 options Image Mode;Infrared, visible, PlP, blending, detail enhancement Temperature Width Stretch;Auto <strong>Measurement and Analysis</strong> App Analysis Function;Central temperature point/Highest temperature point/Lowest temperature point, 1 preset analysis template (support 3 custom points, 3 custom lines, and 3 custom frames) <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB, Bluetooth Remote Access and Control;WiFi, Type-C <strong>Others</strong> Battery;1050 mAh Charging Mode;USB Type-C Battery Life;About 2 h Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~90% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;2G(EC60068-2-6), 25G(EC60068-2-29) Weight and Dimensions;132 g Authentication;CE/RoHS/DGM/WEEE/Measure Packing List;Data cable×1, complete machine×1, quick start guide×1, packing list×1, quality certificate×1

IX2 AIR SE specifications

<strong>Thermal Imaging</strong> Detector Type;12 μm uncooled infrared detector Infrared Resolution;256×192 Spectral Band;7.5–14 μm NETD;＜40mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.75 mrad Focusing Mode;Fixed focus Minimum Imaging Distance; 0.3 m Measurement Range;-20°C ~ +150°C, 100°C ~ +400°C Measurement Accuracy;±2ºC or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Palettes;7 options Image Mode;Infrared Temperature Width Stretch;Auto <strong>Measurement and Analysis</strong> App Analysis Function;Central temperature point/Highest temperature point/Lowest temperature point, 1 preset analysis template (support 3 custom points, 3 custom lines, and 3 custom frames) <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB, Bluetooth Remote Access and Control;WiFi, Type-C <strong>Others</strong> OTA;Support OTA upgrade Battery;1050 mAh Charging Mode;USB Type-C Battery Life;About 2 h Clamp Width;Minimum 131mm/Maximum 172mm Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~90% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;2G(EC60068-2-6), 25G(EC60068-2-29) Weight and Dimensions;130 g Authentication;CE/RoHS/DGM/WEEE/Measure Packing List;Data cable×1, complete machine×1, quick start guide×1, packing list×1, quality certificate×1

IX2 AIR Pro specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;256×192 Pixel Size;12 μm Super Resolution;512×384 Spectral Band;7.5–14 μm NETD;40 mK Frame Rate;25 Hz Lens Focal Length;7 mm FOV;25°×19° IFOV;1.71 mrad Focusing Mode;Manual focusing Minimum Imaging Distance;0.1 m Measurement Range;-20°C ~ +550°C Measurement Accuracy;±2ºC or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Visible Light Camera;2 megapixels Digital Zoom;1×, 2×, 4× Palettes;10 Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;lmages stored in the APP by default and downloadable to a local album <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Up to 3 movable points, lines, and frames, up to 3 preset templates Analysis Report;PDF format, supporting APP-side report generation Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>Video Functions</strong> Radiation Infrared Video Recording;Standard MP4 Radiation Infrared Video Stream Transmission;TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams Video Resolution;512×384 <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB, Bluetooth Voice Control;Voice assistant, quick command recognition <strong>Others</strong> Battery;Built-in 1050 mAh lithium-ion battery Charging Mode;USB Type-C direct charging Battery Life;About 2 h External Interface;USB Type-C Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~90% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 142g,136.2x41x29.3mm Certificates;CE/FCC/ROHS/SRRC/DGM/CMA Package Contents;Thermal camera, Type-C cable, quickstart guide n certificate, certificate of conformity, portable bag

RT400 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;480×360 Pixel Size;12 μm Super Resolution;960×720 Spectral Band;7.5–14 μm NETD;＜35 mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;Standard lens: 17.7 mm, super telephoto lens: 60.9 mm, telephoto lens: 31.5 mm, wide-angle lens: 9.5 mm, macro lens (0.2×): 13 mm, super macro lens (0.4×): 14.8 mm FOV;Standard lens: 25°×20°, super telephoto lens: 7°×5.6°, telephoto lens: 14°×11.2° IFOV;Macro lens: one pixel corresponds to 60 μm, super macro lens: one pixel corresponds to 30 μm. Focusing Mode;Manual focus, electric focus, laser-assisted focus, continuous automatic focus Measurement Range;-20°C~+150°C, 100°C~650°C, optional: 400°C~+1500°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;5-inch OLED touch screen, resolution 1280×720 Visible Light Camera;13 megapixels Digital Zoom;1× ~ 10× Palettes;19 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Support <strong>Image Storage</strong> Storage Medium;Standard 64 GB Micro SD, Support SD, SDHC, SDXC, up to 2 TB Text Notes;Support Voice Annotation;Support <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Support up to 15 movable points, lines, frames, circles and polygons, and up to 5 preset modes Laser Rangefinding;Support Area Measurement;Support Hygrothermograph;Support Position;Support Temperature Difference Analysis;Support Trend Analysis;Supports temperature trend recording and analysis. Image Freezing;Support Analysis Report;PDF format. Support editing and template importing on the PC client. Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>Video Functions</strong> Radiation Infrared Video Recording;Support compressed full radiation video recording (.irv), up to 25Hz video recording. Non-radiation Infrared or Visible Light Video Recording;Standard MP4 video recording Radiation Infrared Video Stream Transmission;TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams Non-radiation Infrared Video Stream Transmission;RTSP H.264 Video Resolution;1280×720 <strong>System Functions</strong> Intelligent Image Stabilization;Support Intelligent Panoramic Stitching;Support panoramic stitching on the PC client, and one-click synthesis. Intelligent Routine Inspection;Support. General task package import and editing, standard and automatic naming of images Routine Inspection Record Self-inspection;Support Dual-Spectrum Video Recording;Simultaneous infrared video and visible light video recording, in MP4 format. Communication Protocol;Wi-Fi, Bluetooth, USB, DP, Type-C to HDMI Voice Control;Voice assistant, quick command recognition Flashlight;Support <strong>Others</strong> Microphone/Speaker;Support Battery Life;Continuous operating time ≥ 6 hours (depending on the actual environment and service conditions) Interface;USB 3.0 Type-C, SD card, SIM card, Mini HDMI Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-20°C~+55°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-40°C~+70°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 1.3 kg (with battery), 144×129×307 mm (subject to actual situations) Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, standard lens, lithium-ion battery×2, charging stand, charger (with plug for use in multiple countries), charging cable, Bluetooth headset, SD card 64G, Type-C cable, lens hood, mold drawing, data download card, calibration certificate, certificate of qualification, hand strap (with buckle), safety box, lens cap (with screws).

RT630 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;640×512 Pixel Size;12 μm Super Resolution;1280×1024 Spectral Band;7.5–14 μm NETD;＜35mK (25°C,F1.0) Frame Rate;25 Hz Lens Focal Length;Standard lens: 17.7 mm, super telephoto lens: 60.9 mm, telephoto lens: 31.5 mm, wide-angle lens: 9.5 mm, macro lens (0.2×): 13mm, super macro lens (0.4×): 14.8 mm. FOV;Standard lens: 25°×20°, super telephoto lens: 7°×5.6°, telephoto lens: 14°×11.2°, wide-angle lens: 45°×36°. IFOV;Standard lens: 0.68 mrad, super telephoto lens: 0.2 mrad, telephoto lens: 0.38 mrad, wide-angle lens: 1.26 mrad, Macro lens: One pixel corresponds to 60 μm, super macro lens: One pixel corresponds to 30 μm. Focusing Mode;Electric micro focus, manual focusing, one-button center focus, automatic center focus, single-touch automatic focusing, laser-assisted focus Measurement Range;-20°C ~ +150°C, 100°C ~ 650°C, optional: 400°C ~ +1500°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;5-inch OLED touch screen, resolution 1280×720 Visible Light Camera;13 megapixels Digital Zoom;1× ~ 10× Palettes;19 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Support <strong>Image Storage</strong> Storage Medium;Standard 64GB Micro SD, Support SD, SDHC, SDXC, up to 2TB Text Notes;Support Voice Annotation;Support <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Support up to 20 movable points, lines, frames, circles and polygons, and up to 5 preset modes Laser Rangefinding;Support Area Measurement;Support Hygrothermograph;Support Position;Support Temperature Difference Analysis;Support Trend Analysis;Supports temperature trend recording and analysis. Image Freezing;Support Analysis Report;PDF format. Support editing and template importing on the PC client. Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>Video Functions</strong> Radiation Infrared Video Recording;Support compressed full radiation video recording (.irv), up to 25Hz video recording. Non-radiation Infrared or Visible Light Video Recording;Standard MP4 video recording Radiation Infrared Video Stream Transmission;TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams Non-radiation Infrared Video Stream Transmission;RTSP H.264 Video Resolution;1280×720 <strong>System Functions</strong> Intelligent Image Stabilization;Support Intelligent Panoramic Stitching;Support panoramic stitching on the PC client, and one-click synthesis. Intelligent Routine Inspection;Support. General task package import and editing, standard and automatic naming of images Routine Inspection Record Self-inspection;Support Dual-Spectrum Video Recording;Simultaneous infrared video and visible light video recording, in MP4 format. Communication Protocol;Wi-Fi, Bluetooth, USB, DP, Type-C to HDMI Voice Control;Voice assistant, quick command recognition Flashlight;Support <strong>Others</strong> Microphone/Speaker;Support Battery;10,000 mAh lithium-ion battery, field-replaceable, support fast charging Charging Mode;USB Type-C or desktop charger Battery Life;Continuous operating time ≥ 6 hours (depending on the actual environment and service conditions) Interface;USB3.0 Type-C, SD card, SIM card, Mini HDMI Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-20°C~+55°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-40°C~+70°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 1.3 kg (with battery), 144×129×307 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, standard lens, lithium-ion battery×2, charging stand, charger (with plug for use in multiple countries), charging cable, Bluetooth headset, SD card 64G, Type-C cable, lens hood, mold drawing, data download card, calibration certificate, certificate of qualification, hand strap (with buckle), safety box, lens cap (with screws).

RS600 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;640×512 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜25mK (25°C, F1.0) Frame Rate; 25 Hz Lens Focal Length;Standard lens: 17.7 mm, super telephoto lens: 60.9 mm, telephoto lens: 31.5 mm, wide-angle lens: 9.5 mm, macro lens (0.2×): 13mm, super macro lens (0.4×): 14.8 mm. FOV;Standard lens: 25°×20°, super telephoto lens: 7°×5.6°, telephoto lens: 14°×11.2°, wide-angle lens: 45°×36°. IFOV;Standard lens: 0.68 mrad, super telephoto lens: 0.2 mrad, telephoto lens: 0.38 mrad, wide-angle lens: 1.26 mrad, Macro lens: One pixel corresponds to 60 μm, super macro lens: One pixel corresponds to 30 μm. Focusing Mode;Electric micro focus, manual focusing, one-button center focus, automatic center focus, single-touch automatic focusing, laser-assisted focus Measurement Range;-20°C~+150°C, 100°C~650°C, optional: 400°C~+1500°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;5.5-inch LCD touch screen, resolution 1920×1080 Visible Light Camera;13 megapixels Digital Zoom;1× ~ 10× Palettes;19 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Support <strong>Image Storage</strong> Storage Medium;Standard 64GB MicroSD. Support SD, SDHC, and SDXC, up to 2TB. Text Notes;Support Voice Annotation;Support <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Support up to 25 movable points, lines, frames, circles and polygons, and up to 5 preset modes Laser Rangefinding;Support Area Measurement;Support Hygrothermograph;Support Position;Support Temperature Difference Analysis;Support Trend Analysis;Supports temperature trend recording and analysis. Image Freezing;Support Analysis Report;PDF format. Support editing and template importing on the PC client. Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>Video Functions</strong> Radiation Infrared Video Recording;Support compressed full radiation video recording (.irv), up to 15 Hz video recording Non-radiation Infrared or Visible Light Video Recording;Standard MP4 video recording <strong>System Functions</strong> Intelligent Routine Inspection;Support. General task package import and editing, standard and automatic naming of images Communication Protocol;Wi-Fi, Bluetooth, USB <strong>Others</strong> Battery;9000 mAh lithium-ion battery, field-replaceable, fast charging Charging Mode;USB Type-C or desktop charger Battery Life;Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions) Interface;USB3.0 Type-C, SD card, SIM card, Mini HDMI Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-15°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-40°C~+70°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 1.3 kg (with battery), 278×116×113 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, manual, calibration certificate, quick operation guide, data download card, certificate of qualification, multi-country adapter, USB data cable, lithium-ion battery×3, portable bag, charging cradle, HDMI cable, hand strap, backpack strap, SD card, charging stand, standard lens.

RS1280 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;1280×1024 Pixel Size;12 μm Super Resolution;2560×2048 Spectral Band;7.5–14 μm NETD;＜25mK (25°C, F1.0) Frame Rate;30 Hz Lens Focal Length;Standard lens: 34.9 mm, wide-angle lens: 19.8 mm, telephoto lens: 72.9 mm, macro lens (0.2×): 17.8 mm, super macro lens (0.4×): 15.2 mm FOV;Standard lens: 25°×20°, telephoto lens: 12°×9.6°, wide-angle lens: 45°×36° IFOV;Standard lens: 0.34 mrad, telephoto lens: 0.17 mrad, wide-angle lens: 0.6 mrad, macro lens: One pixel corresponds to 50 μm, super macro lens: One pixel corresponds to 25 μm. Focusing Mode;Manual focus, electric micro focus, one-button center focus, automatic center focus, single-touch automatic focus, laser-assisted focus Minimum Imaging Distance;Standard lens: 0.5 m, telephoto lens: 2.3 m, wide-angle lens: 0.2 m, macro lens: 46 mm, super macro lens: 13 mm Measurement Range;Standard: -20°C~+150°C (low temperature range), 150°C~800°C (medium temperature range), 400°C~2000°C, other ranges (high temperature range) <strong>Imaging Display</strong> Display;5.5-inch LCD touch screen, 1920×1080 Visible Light Camera;13 megapixels Digital Zoom;1–15 times, continuously adjustable roller Palettes;19 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Support <strong>Image Storage</strong> Storage Medium;Standard 64GB MicroSD. Support SD, SDHC, and SDXC, up to 2TB. Text Notes;Support Voice Annotation;Support <strong>Measurement and Analysis</strong> Laser Rangefinding;Support Area Measurement;Support Position;Support Temperature Difference Analysis;Support Trend Analysis;Supports temperature trend recording and analysis. Image Freezing;Support Analysis Report;PDF format. Support editing and template importing on the PC client. Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP <strong>Video Functions</strong> Radiation Infrared Video Recording;Support compressed full radiation video recording (.irv), up to 15 Hz video recording Non-radiation Infrared or Visible Light Video Recording;Standard MP4 video recording Radiation Infrared Video Stream Transmission;Analysis at about 25 Hz on PC Non-radiation Infrared Video Stream Transmission;RTSP H.264 Video Resolution;1920×1080 <strong>System Functions</strong> Intelligent Image Stabilization;Support Intelligent Panoramic Stitching;Support Intelligent Routine Inspection;Support. General task package import and editing, standard and automatic naming of images Routine Inspection Record Self-inspection;Support Dual-Spectrum Video Recording;Simultaneous infrared video and visible light video recording, in MP4 format. Communication Protocol;Wi-Fi, Bluetooth, USB Voice Control;Voice assistant, quick command recognition Flashlight;Support <strong>Others</strong> Microphone/Speaker;Support Battery;9000 mAh lithium-ion battery, field-replaceable, fast charging Charging Mode;USB Type-C or desktop charger Battery Life;Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions) Interface;USB3.0 Type-C, SD card, SIM card, Mini HDMI Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature; -15°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-40°C~+70°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;<1.7 kg (with battery), 140×210×115 mm Authentication;CE/RoHS/CMA, etc.

RM200A specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;256×192 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜40mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;3.2 mm FOV;56°×42° IFOV;3.75 mrad Focusing Mode;Fixed focus Minimum Imaging Distance;0.3 m Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch touch screen, 640×480 Visible Light Camera;2 megapixels Digital Zoom;1× 2× 4× Palettes;7 options Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;Standard 32GB MicroSD, up to 128G Text Notes;Support Voice Annotation;Support Image Naming;Auto/manual naming, naming by scanning QR code <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Custom points/lines/areas. Up to 10 points, 10 areas, and 10 lines. Center point/Hot and cold spot tracking and temperature display Supporting Software;PC (Infrared Analysis Software) <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Video Transmission;Support UVC video transmission Laser Pointer;Support <strong>Others</strong> Battery;Rechargeable and detachable lithium-ion battery Charging Mode;USB Type-C or desktop charger Battery Life;About 8 h (about 4 h for a single battery) Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 635 g, 258.4×105.1×102.3 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, 5V 2A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, portable cloth bag

RM200F specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;256×192 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜40 mK (25°C, F1.0) Frame Rate;25 Hz Lens Focal Length;7 mm FOV;24.8°×18.7° IFOV;1.71 mrad Focusing Mode;Manual focusing Minimum Imaging Distance;0.2 m Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch touch screen, 640×480 Visible Light Camera;2 megapixels Digital Zoom;1× 2× 4× Palettes;10 Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;Standard 32 GB MicroSD, up to 128 GB Text Notes;Support Voice Annotation;Support Image Naming;Auto/manual naming, naming by scanning QR code <strong>Measurement and Analysis</strong> Analysis Functions on the Device; Custom points/lines/areas. Up to 10 points, 10 areas, and 10 lines. Center point/Hot and cold spot tracking and temperature display Supporting Software;PC (Infrared Analysis Software) <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Video Transmission;Support UVC video transmission Laser Pointer;Support <strong>Others</strong> Battery;Rechargeable and detachable lithium-ion battery Charging Mode;USB Type-C or desktop charger Battery Life;About 8h (about 4h for a single battery) Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 660 g, 258.4×105.1×102.3 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, 5V 2A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, portable cloth bag Cloud Services;Support cloud drive storage, support auto time sync

RM305 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;384×288 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜35 mK (25°C, F1.0) Frame Rate;30 Hz Lens Focal Length;6.2 mm FOV;43.7°×31.9° IFOV;1.98 mrad Focusing Mode;Manual focusing Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch touch screen, 640×480 Visible Light Camera;5 megapixels Digital Zoom;1×, 2×, 4×, 8× Palettes;10 Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;Standard 32 GB MicroSD, up to 512 GB Text Notes;Support Voice Annotation;Support Image Naming;Auto/manual naming, naming by scanning QR code <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Custom points/lines/areas. Up to 10 points, 10 areas, and 10 lines. Center point/Hot and cold spot tracking and temperature display Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Video Transmission;Support UVC video transmission Laser Pointer;Support <strong>Others</strong> Battery;Rechargeable and detachable lithium-ion battery Charging Mode;USB Type-C or desktop charger Battery Life;About 6 h (about 3 h for a single battery) Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25 g (IEC 60068-2-27), vibration: 2.5 g (IEC60068-2-6) Weight and Dimensions;About 670 g, 258.4×105.1×102.3 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box

RM320 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;384×288 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜35 mK (25°C, F1.0) Frame Rate;30 Hz Lens Focal Length;9.1 mm FOV;27°×20° IFOV;1.31 mrad Focusing Mode;Manual focusing Measurement Range;-20°C~+150°C, 100°C~650°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch touch screen 640×480 Visible Light Camera;5 megapixels Digital Zoom;1×, 2×, 4×, 8× Palettes;10 Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;Standard 32 GB MicroSD, up to 512 GB Text Notes;Support Voice Annotation;Support <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Custom points/lines/areas. Up to 10 points, 10 areas, and 10 lines. Center point/Hot and cold spot tracking and temperature display Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>Video Functions</strong> Radiation Infrared Video Recording;Support Non-radiation Infrared or Visible Light Video Recording;Support <strong>System Functions</strong> Intelligent Routine Inspection;Support Communication Protocol;Wi-Fi, USB Video Transmission;Support UVC video transmission Laser Pointer;Support <strong>Others</strong> Battery;Rechargeable and detachable lithium-ion battery Charging Mode;USB Type-C or desktop charger Battery Life;About 6h (about 3h for a single battery) Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 683.5 g, 258.4×105.1×102.3 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box

RM600G specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;640×512 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜35 mK (25°C, F1.0) Frame Rate;30 Hz Lens Focal Length;9.1 mm FOV;48°×38° IFOV;1.31 mrad Focusing Mode;Manual focusing Measurement Range;-20°C~+150°C, 100°C~550°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch touch screen, 640×480 Visible Light Camera;5 megapixels Digital Zoom;1×, 2×, 4×, 8× Palettes;10 Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;Standard 32 GB MicroSD, up to 512 GB Text Notes;Support Voice Annotation;Support Image Naming;Auto/manual naming, naming by scanning QR code <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Custom points/lines/areas. Up to 10 points, 10 areas, and 10 lines. Center point/Hot and cold spot tracking and temperature display Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>System Functions</strong> Communication Protocol;Wi-Fi, USB Video Transmission;Support UVC video transmission Laser Pointer;Support <strong>Others</strong> Battery;Rechargeable and detachable lithium-ion battery Charging Mode;USB Type-C or desktop charger Battery Life;About 6 h (about 3 h for a single battery) Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 670 g, 258.4×105.1×102.3 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box

RM620 specifications

<strong>Thermal Imaging</strong> Detector Type;Uncooled infrared detector Infrared Resolution;640×512 Pixel Size;12 μm Spectral Band;7.5–14 μm NETD;＜35 mK (25°C, F1.0) Frame Rate;30 Hz Lens Focal Length;19 mm FOV;23°×18° IFOV;0.63 mrad Focusing Mode;Manual focusing Measurement Range;-20°C~+150°C, 100°C~650°C Measurement Accuracy;±2°C or ±2% of readings, whichever is greater <strong>Imaging Display</strong> Display;3.5-inch touch screen, 640×480 Visible Light Camera;5 megapixels Digital Zoom;1×, 2×, 4×, 8× Palettes;10 Image Mode;Infrared, visible light, PIP, dual-spectrum fusion Temperature Width Stretch;Automatic/Manual <strong>Image Storage</strong> Storage Medium;Standard 32 GB MicroSD, up to 512 GB Text Notes;Support Voice Annotation;Support <strong>Measurement and Analysis</strong> Analysis Functions on the Device;Custom points/lines/areas. Up to 10 points, 10 areas, and 10 lines. Center point/Hot and cold spot tracking and temperature display Supporting Software;PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) <strong>Video Functions</strong> Radiation Infrared Video Recording;Support Non-radiation Infrared or Visible Light Video Recording;Support <strong>System Functions</strong> Intelligent Routine Inspection;Support Communication Protocol;Wi-Fi, USB Video Transmission;Support UVC video transmission Laser Pointer;Support <strong>Others</strong> Battery;Rechargeable and detachable lithium-ion battery Charging Mode;USB Type-C or desktop charger Battery Life;About 6 h (about 3 h for a single battery) Interface;USB Type-C, SD card Tripod Socket;UNC 1/4-20 interface for tripod Operating Temperature;-10°C~+50°C Operating Humidity;10%~95% (non-condensing) Storage Temperature;-20°C~+60°C Ingress Protection Rating;IP54 Shock and Vibration;Shock: 25g (IEC 60068-2-27), vibration: 2.5g (IEC60068-2-6) Weight and Dimensions;About 680 g, 258.4×105.1×102.3 mm Authentication;CE/RoHS/CMA, etc. Packing List;Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box
