Raythink RT400

Compact and lightweight handheld thermal imaging camera with a 480×360 IR sensor AI-enhanced to 960×720, 35 mK NETD, a 5-inch touchscreen, interchangeable lenses and a built-in voice assistant


Expert Tool

If you're looking for an advanced yet compact thermal camera, consider the Raythink RT400. It features a 12 µm uncooled infrared detector with a native resolution of 480×360, enhanced by real-time AI to 960×720. With a NETD under 35 mK, it accurately detects subtle thermal anomalies across -20°C to 650°C, with an optional extension up to 1500°C for high-temperature applications. A bright 5-inch OLED touchscreen provides clear visualization, and built-in tools support in-depth thermal analysis. Interchangeable lenses, intelligent image stabilization, laser rangefinding, and versatile focus options make the RT400 suitable for close-up inspections or long-range monitoring, while its IP54-rated rugged housing ensures reliable performance in demanding industrial environments.

Raythink RT400 key features and advantages

  • Measurement range -20℃ to 650℃, optional 400°C to 1500°C

  • NETD <35 mK for detecting small temperature differences

  • 480×360 infrared resolution enhanced to 960×720 with real-time AI

  • Runs on Android OS for simpler, more efficient operation

  • 5-inch OLED touchscreen

  • Built-in intelligent stabilization ensures smoother, more consistent imaging

  • Macro-lens support for versatile use

  • Standard 25° lens with optional wide-angle, telephoto, and super-telephoto lenses

  • Laser rangefinding and area measurement support

  • Built-in 13MP visible light camera

  • Up to 15 points, lines, and areas supported for detailed temperature analysis

  • IP54-rated for dust and water protection

How Raythink RT400 works

The Raythink RT400 captures infrared data with its 12 µm 480×360 sensor, enhanced by real-time AI super-resolution to 960×720. With NETD below 35 mK, it detects subtle temperature differences, and the auto-ranging system covers -20 °C to 650 °C, optionally up to 1500 °C. Data appears on a 5‑inch OLED touchscreen, with built-in tools for precise analysis. Interchangeable lenses, image stabilization, laser rangefinder, and Android-based controls make the RT400 versatile and field-ready, while its IP54-rated housing ensures reliable performance in harsh inspection conditions.

Raythink RT400 applications

Raythink RT400 can be widely used in high temperature material monitoring, electronic and electrical R&D, electric routine inspection, chemical operation and maintenance, and other fields.

  • High temperature material monitoring

  • Electronic and electrical R&D

  • Electric routine inspection

  • Chemical operation and maintenance
