Raythink RS600

Advanced handheld thermal imaging camera featuring a 640×512 IR sensor AI-enhanced to 1280×1024, 25 mK NETD, a 5.5-inch tilting touchscreen, interchangeable lenses, and intelligent image stabilization


When Precision and Ergonomics Are Paramount

Now things get serious. The Raythink RS600 is more than a gadget, it is a professional-grade instrument built with some of the most advanced thermal imaging technologies available. This ergonomic, field-ready device uses a 12 µm uncooled infrared sensor with a native 640×512 resolution, enhanced by real-time AI super-resolution to 1280×1024 for razor-sharp thermal images. With a NETD below 25 mK, it captures even faint thermal variations, and its auto-ranging spans -20°C to 650°C, extendable to 1500°C for extreme-heat applications. A 5.5-inch tilting OLED touchscreen provides clear, flexible viewing, while onboard tools support detailed diagnostics from trend analysis to area measurements. Interchangeable lenses, intelligent image stabilization, a laser rangefinder, and Android-based controls make the RS600 adaptable for both close-up inspections and long-range monitoring. Its IP54-rated enclosure ensures reliable performance even in harsh industrial environments.

Raythink RS600 key features and advantages

  • Measurement range -20℃ to 650℃, optional 400°C to 1500°C

  • NETD <25 mK for detecting small temperature differences

  • 640×512 infrared resolution enhanced to 1280×1024 with real-time AI

  • Runs on Android OS for simpler, more efficient operation

  • 5.5-inch tilting OLED touchscreen

  • Built-in intelligent stabilization ensures smoother, more consistent imaging

  • Macro-lens support for versatile use

  • Standard 25° lens with optional wide-angle, telephoto, and super-telephoto lenses

  • Laser rangefinding and area measurement support

  • Built-in 13MP visible light camera

  • Up to 25 points, lines, and areas supported with 5 presets for detailed temperature analysis

  • IP54-rated for dust and water protection

How Raythink RS600 works

The Raythink RS600 uses a 12 µm 640×512 sensor with real-time AI super-resolution to 1280×1024 and a <25 mK NETD for detecting subtle temperature differences. It auto-ranges from -20°C to 650°C, optionally up to 1500°C, and displays data on a 5.5-inch tilting OLED touchscreen with built-in diagnostic tools, including trend analysis and area measurement. Interchangeable lenses, image stabilization, a laser rangefinder, and Android-based controls provide versatility in the field, while the IP54-rated housing ensures reliable performance in demanding inspection conditions.

Raythink RS600 applications

Raythink RS600 can be widely used in high temperature material monitoring, electric routine inspection, high-end scientific research, chemical operation and maintenance, and other fields.

  • High temperature material monitoring

  • High-end scientific research

  • Electric routine inspection

  • Chemical operation and maintenance
