Raythink RS1280

Advanced handheld thermal imaging camera featuring a 1280×1024 IR sensor AI-enhanced to 2560×2048, 25 mK NETD, a 5.5-inch tilting touchscreen, interchangeable lenses, and intelligent image stabilization


Flagship Infrared Technologies in a Handheld Tool

The Raythink RS1280 represents the top tier of handheld thermal imaging, engineered for experts who demand uncompromising accuracy and true operational comfort. At its core is a high-performance 12 µm uncooled infrared detector delivering a native 1280×1024 resolution, further enhanced to 2560×2048 by advanced imaging algorithms for exceptional clarity. With a NETD below 25 mK, the RS1280 uncovers barely perceptible thermal variations, and its measurement range spans -20 °C to 2000 °C for extreme-temperature applications. A bright 5.5-inch tilting OLED touchscreen provides flexible viewing from any angle, while onboard diagnostic tools support detailed analysis including trend tracking and area measurements. Interchangeable lenses, intelligent image stabilization, multiple focusing modes, a built-in laser rangefinder, full Android-based controls, and an IP54-rated housing make the RS1280 adaptable to virtually any inspection scenario.

Raythink RS1280 key features and advantages

  • Measurement range -20℃ to 2000°C

  • 1280×1024 infrared resolution enhanced to 2560×2048 with real-time AI

  • NETD 25 mK for detecting small temperature differences

  • Runs on Android OS for simpler, more efficient operation

  • 5.5-inch tilting OLED touchscreen

  • Built-in intelligent stabilization ensures smoother, more consistent imaging

  • Supports up to 35 points, lines, and areas for detailed on-screen temperature analysis

  • Laser rangefinding and area measurement

  • Standard 25° lens, with optional wide-angle, telephoto, super telephoto, and macro lenses

  • Built-in 13MP visible light camera

  • Several focusing methods, including manual focus, auto focus, laser-assisted focus, and continuous auto focus

  • IP54-rated for dust and water protection

How Raythink RS1280 works

The Raythink RS1280 uses a 12 µm 1280×1024 sensor with real-time AI super-resolution to 2560×2048 and a <25 mK NETD for detecting subtle temperature differences. It auto-ranges from -20 °C to 2000 °C and displays data on a 5.5-inch tilting OLED touchscreen with built-in diagnostic tools, including trend analysis and area measurement. Interchangeable lenses, image stabilization, a laser rangefinder, and Android-based controls provide versatility in the field, while the IP54-rated housing ensures reliable performance in harsh industrial environments.

Raythink RS1280 applications

Raythink RS1280 can be widely used in microelectronics, electric routine inspection, high-end scientific research, nondestructive testing, and other fields.

  • Microelectronics

  • High-end scientific research

  • Electric routine inspection

  • Nondestructive testing
