Raythink RM620

Compact and lightweight handheld thermal imaging camera with a 640×512 IR sensor, 35 mK NETD, 23°×18° field of view, and a 3.5-inch touchscreen


Serious Performance for Serious Tasks

From subtle hot spots to a full-scene scans, the Raythink RM620 gets the job done. Built for professionals, the RM620 uses a 12 µm uncooled 640×512 infrared detector with 35 mK NETD for detecting even slight temperature differences. The device offers advanced features for simplifying task management and improving routine inspection efficiency, including intelligent shooting, user customization, and import and distribution of inspection task packages. Built-in temperature trend analysis helps users observe temperature distribution and changes in real time, and the isotherm function highlights key segments and areas that need attention. Its rugged IP54-rated housing with 2-meter drop resistance ensures reliability in harsh environments, while real-time full-frame transmission and compatibility with PC and mobile diagnostic software keeps workflows efficient across a wide range of scenarios.

Raythink RM620 key features and advantages

  • 640×512 uncooled infrared sensor

  • Bright 3.5-inch touchscreen

  • Measurement range from -20°C to 650°C

  • NETD <35 mK for detecting small temperature differences

  • Built-in 5 MP visible light camera

  • IP54-rated housing designed to survive 2 m drops

  • Laser pointer for rapid targeting of temperature anomalies

  • Intelligent shooting, user-defined settings, and import or sharing of inspection task packages

  • Two quick-swap batteries providing up to 6 hours of runtime

  • Professional thermal imaging analysis software on mobile and PC

  • Temperature trend analysis

  • Isotherm function to highlight temperature segments and areas that need attention

How Raythink RM620 works

The Raythink RM620 captures detailed infrared data with its 12 µm 640×512 sensor. With a NETD below 35 mK, it detects subtle temperature differences across a -20°C to 650°C range. A 3.5-inch LCD touchscreen provides crisp, easy-to-read thermal images. Equipped with a laser pointer and offering up to 6 hours of battery life, the RM620 is versatile and ready for field use, while its IP54-rated housing with 2-meter drop resistance ensures dependable performance in demanding industrial environments.

Raythink RM620 applications

Raythink RM620 can be widely used in circuit design, construction inspection, electric routine inspection, industrial manufacturing, and other fields.

  • Circuit design

  • Construction inspection

  • Electric routine inspection

  • Industrial manufacturing
