Raythink CX20 Pro
Compact handheld thermal camera with real-time AI-enhanced resolution up to 512×384, Wi-Fi, a laser pointer and a 3.5-inch HD display
Compact Tool Built For Tough Jobs
The Raythink CX20 Pro is a handheld thermal camera built for users who need fast, dependable thermal diagnostics in the field. It starts with a 256×192 infrared sensor and applies real-time AI super-resolution to deliver sharp 512×384 thermal images on a 3.5-inch HD display. With 40 mK NETD sensitivity, it detects subtle temperature differences essential for electrical inspections, HVAC diagnostics, and equipment maintenance. Built-in Wi-Fi and UVC enable quick image transmission, while the laser pointer helps with fast targeting of temperature anomalies.
Raythink CX20 Pro key features and advantages
-
256×192 infrared resolution enhanced to 512×384 with real-time AI
-
NETD ＜40 mK for detecting small temperature differences
-
3.5-inch high-resolution display for detailed thermal imaging
-
Measurement range -20℃ to 550℃ with automatic range switching
-
Data sharing via UVC and Wi-Fi, compatible with PCs and app software
-
18W quick charging ensures worry-free performance during intensive operations
-
32GB built-in memory for extensive data storage
-
IP54-rated for dust and water protection, built to withstand drops up to 2 meters
-
Professional mobile/PC temperature analysis platform, supporting secondary analysis
-
Upgraded laser pointer for fast targeting of temperature anomalies
How Raythink CX20 Pro works
Raythink CX20 Pro uses a 256×192 IR sensor and applies real-time AI super-resolution to produce clean 512×384 images. Its 40 mK NETD lets you detect subtle temperature differences, and the laser pointer makes it easy to pinpoint problem areas. The device auto-ranges from -20°C to 550°C and displays or records all data on the 3.5-inch high-resolution screen, with UVC and Wi-Fi output for a larger view when needed. With long battery life and an IP54-rated build, it’s engineered for reliable field performance.
Raythink CX20 Pro applications
Raythink CX20 Pro can be widely used in circuit maintenance, power maintenance, HVAC leak detection, equipment maintenance and other fields.
-
Circuit maintenance
-
Power maintenance
-
HVAC leak detection
-
Equipment maintenance
