Raythink RM200F

Compact and lightweight handheld thermal imaging camera with a 256×192 IR sensor, 40 mK NETD, 24.8°×18.7° field of view, and a 3.5-inch touchscreen


Easy-to-Carry Professional Thermal Imaging Solution

Raythink RM200F is a compact handheld thermal imaging camera featuring a 12 µm uncooled 256×192 infrared sensor. Thanks to a NETD below 40 mK, the RM200F detects small temperature differences across its -20°C to 550°C measurement range. A bright 3.5-inch touchscreen provides clear, convenient viewing, while the built-in laser pointer, 2 MP video recording and IP54-rated housing ensure reliable performance in any scenario. The device also supports cloud storage and automatic time synchronization for streamlined data management.

Raythink RM200F key features and advantages

  • Measurement range from -20°C to 550°C with manual range adjustment

  • Intelligent high-precision thermal measurement with advanced HD imaging algorithms

  • Laser pointer for rapid targeting of temperature anomalies

  • NETD <40 mK for detecting small temperature differences

  • Bright 3.5-inch touchscreen

  • 256×192 uncooled infrared sensor

  • Built-in 2MP visible light camera

  • Two quick-swap batteries providing up to 8 hours of runtime

  • IP54-rated housing designed to survive 2 m drops

  • Supports cloud storage and automatic time synchronization

How Raythink RM200F works

The Raythink RM200F captures detailed infrared data with its 12 µm 256×192 sensor. With a NETD below 40 mK, it identifies subtle temperature differences across a -20°C to 550°C range. A 3.5-inch LCD touchscreen delivers crisp, easy-to-read thermal images that can be uploaded to the cloud for easy access and backup. Equipped with a laser pointer and offering up to 8 hours of battery life, the RM200F is versatile and ready for field use, while its IP54-rated housing with 2-meter drop resistance ensures reliable operation in demanding industrial environments.

Raythink RM200F applications

Raythink RM200F can be widely used in HVAC maintenance, equipment maintenance, circuit design, power maintenance, and other fields.

  • HVAC maintenance

  • Equipment maintenance

  • Circuit design

  • Power maintenance
