Raythink EX10
Compact handheld thermal camera with real-time AI-enhanced resolution up to 320×240 and a 2.8-inch display
A Powerful Thermal Camera in a Compact Form
The Raythink EX10 brings high-grade thermal imaging to a handheld device that fits easily into any toolkit. Its 160×120 infrared detector, enhanced to a sharp 320×240 through real-time AI super resolution, delivers clear and reliable thermal visuals on a bright 2.8-inch display. With UVC support and long operating time, the EX10 is ideal for home maintenance, electrical troubleshooting, HVAC leak detection, and automotive diagnostics.
Raythink EX10 key features and advantages
-
160×120 infrared resolution enhanced to 320×240 with real-time AI
-
NETD <40 mK for detecting temperature differences as small as 0.04 °C
-
2.8-inch display showing detailed thermal images
-
Measurement range -20℃ to 550℃ with automatic range switching
-
UVC real-time image transmission compatible with PC and app software for further analysis
-
Quick start-up with up to 10 hours of continuous operation
-
8GB built-in memory for extensive data storage
-
IP54-rated for dust and water protection, built to withstand drops up to 2 meters
How Raythink EX10 works
Raythink EX10 uses a 160×120 IR sensor and applies real-time AI super-resolution to produce a cleaner 320×240 image, with a 40 mK NETD for detecting even subtle temperature shifts. The device auto-ranges from -20°C to 550°C and shows or records everything on the 2.8-inch display, with UVC output when you need a bigger screen. With quick start-up, long run time, and an IP54 build, it’s engineered to stay reliable in the field.
Raythink EX10 applications
Raythink EX10 can be widely used in household maintenance, electrical maintenance, HVAC leak detection, automotive repairs and other fields.
-
Household maintenance
-
Automotive maintenance
-
HVAC leak detection
-
Equipment maintenance
