GasFIR G-Series
GasFIR G-Series cameras are handheld thermal imagers designed to detect methane and VOC leaks. They enable rapid inspection of large areas and accurate real-time leak source localization. The cameras are intrinsically safe and comply with EPA OOOOa requirements.
Portable solution for visual detection of methane and VOC leaks
Pergam GasFIR G630, G630M, G630R, and G630Q are cutting-edge OGI cameras designed to detect hydrocarbons, methane, and other volatile organic compounds with speed and precision. Each model is tailored to specific needs: G630M features a laser methane detector with a 60-meter range, G630R includes a powerful 400-meter laser rangefinder, and G630Q offers built-in gas quantification to measure leak type and severity without additional equipment. Easy to use and highly effective, the GasFIR series helps reduce gas leaks by up to 99%, making operations safer and more efficient.
Explosion-proof rating Ex 2Ex ic nC op is IIC T4 Ge X
Explosion-proof rating Ex 2Ex ic nC op is IIC T4 Ge X
GasFIR G630-series cameras are intrinsically safe and complies with the EPA’s (OOOOa) requirements.
GasFIR G-Series Key Features
-
Real-time gas leak visualization
at distances of up to 180 m. -
Gas leak quantification
with the G630Q model. -
Laser methane detection
with the G630M model. -
Laser rangefinding
with the G630R model. -
Image and video recording
for leak inspection and documentation. -
Versatile connectivity
via USB, WLAN, 4G, and HDMI. -
OLED viewfinder
with adjustable tilt angle. -
Built-in OS
with an intuitive interface.
GasFIR G-Series Main Specifications
-
Cooled
Detector type -
3.2–3.4 µm
Spectral range -
320 × 256
Detector resolution -
30 Hz
Frame rate -
≤15 mK
NETD at 25°C -
180 m
Maximum leak detection distance -
-40°C to +350°C
Temperature range -
IP66
Protection rating
Target gases
Methane, propane, butane, pentane, ethylene, hexane, propanol, butadiene, butene, pentene, styrene, toluene, xylene, dimethylbenzene, isobutylene, isoprene, benzene, ethylbenzene, hexane, ethylene oxide, methanol, propylene oxide, propylene, ethane, octane, heptane, isopropyl alcohol, acetic acid, butanone, NGL
Why Choose GasFIR G-Series
-
Real-time visualization of gas leaks
without physical contact. -
Detection of methane
and a wide range of hydrocarbons and VOCs. -
Model-specific options
for methane detection, rangefinding, and gas quantification. -
ATEX certification
for hazardous-area use. -
Handheld design
with a high-resolution display and adjustable viewfinder. -
Built-in GPS
and multiple data transfer interfaces.
How GasFIR G-series works
GasFIR G-series makes invisible gas leaks visible by visualizing infrared contrast created as specific industrial gases absorb background IR radiation. Using special filters, the camera shows gas plumes on the screen in real time, allowing for safe and efficient leak detection without physical contact.
How GasFIR G-Series works
GasFIR G-series makes invisible gas leaks visible by visualizing infrared contrast created as specific industrial gases absorb background IR radiation. Using special filters, the camera shows gas plumes on the screen in real time, allowing for safe and efficient leak detection without physical contact.
About laser methane detection
Laser methane detector of GasFIR G630M utilizes TDLAS technology
TDLAS (Tunable Diode Laser Absorption Spectroscopy) technology uses a tunable diode laser for precise gas analysis. The laser emits a narrow beam of light at a specific wavelength that matches the absorption characteristics of the target gas. When this beam passes through the gas and reflects off a surface, part of the light is absorbed by gas molecules. A sensor captures the reflected beam, and the gas concentration is determined by measuring the reduction in light intensity.
GasFIR G-Series applications
The GasFIR G-Series is an effective and reliable solution for monitoring even hard-to-reach areas during the extraction, transportation, processing, and use of oil and gas products.
-
Petrochemical industry
-
Power industry
-
Chemical industry
-
Factories
-
Infrastructure facilities
-
Gas pipelines
FAQ
Honest answers to important questions
GasFIR G-Series is designed for visual detection of methane and a wide range of hydrocarbons and volatile organic compounds (VOCs). The detectable gases include propane, butane, ethylene, benzene, toluene, xylene, ethane, and other gases listed in the technical specifications.
GasFIR G-Series uses optical gas imaging (OGI) to visualize infrared radiation absorbed by specific gases. Special optical filters make the gas plume visible on the camera display in real time, so the leak can be located without physical contact.
The maximum leak detection distance is up to 180 m, depending on the conditions and the gas being detected.
Yes. The camera provides remote temperature measurement from -40°C to +350°C.
The models have different additional functions. The G630M includes a laser methane detector with a detection distance of up to 60 m. The G630R is equipped with a laser rangefinder. The G630Q provides quantitative gas leak analysis. The G630 is the standard model without these additional functions.
Yes. The G630M uses TDLAS (Tunable Diode Laser Absorption Spectroscopy) for remote methane detection. Its measuring range is 0–10% vol or 0–100,000 ppm×m, with a detection distance of up to 60 m.
Yes. The G630-series cameras are designed for use in hazardous environments and have the explosion-protection marking Ex 2Ex ic nC op is IIC T4 Ge X.
Yes. The camera can store JPEG images and H.264 video on a 128 GB TF card. Images can also contain voice and text annotations.
GasFIR G-Series supports USB, WLAN, 4G, and HDMI interfaces. Wi-Fi can also be used to transfer images to an external monitor using the available application.
The camera provides at least 3 hours of continuous operation on a rechargeable 12 V Li-Ion battery.
