GasFIR 309

Specifications

<strong>Detector and lens</strong> Resolution;320 × 256 Pixel pitch;30 µm NETD;≤15mK@25 °С Spectral range;InSb detector/ 3.8 – 4.05 µm Traceable gases;Methane, ethane, propane, butane, ethylene, propylene, benzene, ethanol, ethylbenzene, heptane, hexane, isoprene, methanol, MEK, MIBK, octane, pentane, 1-pentene, toluene, xylene Lens;Standard 24° × 19° / Optional 14.5° × 11.6° Focus;Motorized, manual/auto <strong>Display Mode</strong> IR image;Full-color IR imaging Visible image;Full-color visible imaging Image fusion;Double band Fusion Mode (DB-Fusion™: Stack the IR image with detailed visible image info so that IR radiation distribution and visible outline info are displayed at the same time) Picture in picture;A movable and size-alterable IR image on top of visible image Storage (Playback);View thumbnail/full picture on device<br>Edit measurement/color palette/imaging mode on device <strong>Display</strong> Screen;5” LCD touch screen with 1024 × 600 resolution Viewfinder;0.39” OLED with 1024 × 600 resolution Visible camera;CMOS, auto focus, equipped with one supplement light source Color template;10 types + 1 customizable Zoom;10X digital continuous zoom Image adjustment;Manual/auto adjustment of brightness and contrast <strong>Temperature detection</strong> Detection range;-20°С ~ +1500°С (-4°F to 2732°F) Accuracy;±2°С or ±2% (maximum of absolute value) Temperature analysis;10 points analysis<br>10 + 10 area (10 rectangle, 10 circle) analysis, including min/max/average<br>Linear analysis<br>Isothermal analysis<br>Temperature difference analysis<br>Auto max/min temperature detection: auto min/max temp label on full screen/area/line Temperature alarm;Coloration alarm (Isotherm): higher or lower than designated temperature level, or in between designated levels<br>Measurement alarm: audio/visual alarm (higher or lower than designated temperature level) Measurement correction;Emissivity (0.01 to 1.0, or chosen from the material emissivity list), reflective temperature, relative humidity, atmosphere temperature, object distance, external IR window compensation <strong>File Storage</strong> Storage media;Removable TF card 32G, class 10 or higher recommended Image format;Standard JPEG, including digital image and full radiation detection data Image storage mode;Storage both IR and visible image in the same JPEG file Image comments;Audio: 60 second, stored with images<br>Text: Chosen among the preset templates Radiation IR video (with RAW data);Real-time radiation video record, to TF card Non-radiation IR video;H.264, to TF card Visible video record;H.264, to TF card Timed photo;3 sec ~ 24hr <strong>Port</strong> Video output;HDMI Port;USB and WLAN, image, video and audio can be transferred to computer <strong>Others</strong> Setting;Date, time, temperature unit, language Laser indicator;2nd level, 1 mW/635 nm red <strong>Power Source</strong> Battery;lithium battery, capable of continuous working >3hr under 25°С (77°F) normal use condition External power source;12 V adaptor Startup time;About 7 min under normal temperature Power management;Auto shut-down/sleep, can be set in between “never”, “5 mins”, “10 mins”, “30mins” <strong>Environmental Parameter</strong> Working temperature;-20°С ~ +50°С (-4°F ~ 122°F) Storage temperature;-30°С ~ +60°C (-22°F ~ 140°F) Working humidity;≤95% Ingress protection;IP54 Shock test;30g, duration 11 ms Vibration test;Sine wave 5Hz ~ 55Hz ~ 5Hz, amplitude 0.19 mm <strong>Dimensions and mounting</strong> Weight;≤2.8 kg (6 lb) Size;310 × 175 × 150mm (standard lens included) Tripod;Standard, 1/4”
